4-7
INITIAL SETTING
The "number of measurements
for averaging" and "hysteresis"
can be changed if required.
These parameters are to be
set at the advanced-function
setting level.
Clear All
If you are confused about how parameters have been set during initial setting, you
can clear all the parameters and start all over again.
For details on how to clear all parameters, refer to "5-17 Clearing All Parameters".
4-3 K3MA-F (Frequency/Rate meter)
1. Make sure the main indicator displays the current process value (the prod-
uct is at the operation level). Then press the L key for at least three sec-
onds. The product will move to the initial setting level.
2. Since it is considered that, taking the application into account, input fre-
quency may be around 2 Hz, may be less than 30 Hz at all events, set the
parameter at the initial setting level "p-fre" to "30".
C. Specify the scaling factor.
1. Set parameter "inp" to "10.00".
2. Set parameter "dsp" to "56549".
D. Specify the "decimal point position".
1. Set parameter "dp" to "\\.\\\".
E. Set "OUT1 value type" to "upper limit", and "OUT2 value type" to "lower limit".
1. Set parameter "out1.t" to "hi".
2. Set parameter "out2.t" to "lo".
F. Set the OUT1 value to "10.500" and the OUT2 value to "9.500".
1. Make sure the main indicator displays an initial setting level parameter.
Then press the L key for at least one second. The product will move to the
operation level.
2. Set parameter "out1" to "10.500".
3. Set parameter "out2" to "9.500".
G. Bring the product into measuring operation.
*For details on parameter setting, refer to "CHAPTER 5 OPERATION".
