5-8
OPERATION
Available OUT set values and their indications are as follows.
(With K3MA-L, OUT2 value, OUT2 upper-limit value, and OUT2 lower limit value
are not available.)
For details of comparative output, refer to "6-5 Comparative Output".
OUT set value Indication
Description
OUT1 value out1
When the process value increases or
decreases to this value, comparative output
1 is provided.
OUT1 upper-limit
value
out1.h
When the process value falls outside-the-
range specified by these values, compara-
tive output 1 is provided.
OUT1 lower-limit
value
out1.l
OUT2 value out2
When the process value increases or
decreases to this value, comparative output
2 is provided.
OUT2 upper-limit
value
out2.h
When the process value falls outside-the-
range specified by these values, compara-
tive output 2 is provided.
OUT2 lower-limit
value
out2.l
CHAPTER 5 OPERATION
