36
Available functions in this mode are indicated as “Yes” in the following table.
Menu Function Displayed
Character
Availability Reference
page
---
Max./Min. value display and reset --- Yes 103
Estimated frequency calculation --- Yes 129
sUset
(S 2)
Set value bank no. of set values
s.bank
Yes 50
(See note 2)
HH set value
sU*.hh
H set value
sU*. h
L set value
sU*. l
LL set value
sU*.ll
pscl
Select bank no. of prescale value
p.bank
Yes
54
Prescaling value of input A
X (mantissa)
Y (exponent)
ps*.ax
ps*.ay
Yes
Prescaling value of input B
X (mantissa)
Y (exponent)
ps*.bx
ps*.by
Yes
Decimal point position
decp.*
Yes
setup
Operating mode
func
Yes 58
Input A sensor type
ina
Yes
60
Input B sensor type
inb
No
Auto zero time of input A
X (mantissa)
Y (exponent)
=ro.ax
=ro.ay
Yes
62
Auto zero time of input B
X (mantissa)
Y (exponent)
=ro.bx
=ro.by
Yes
Display time unit
time
No 65
Communications unit no. (See note 1)
uĆno
Yes
67
Baud rate (See note 1)
bps
Yes
Word length (See note 1)
len
Yes
69
Stop bits (See note 1)
sbit
Yes
Parity bits (See note 1)
prty
Yes
opt
Process time for averaging measured value
aUg
Yes 72
Startup compensation time
stime
Yes 74
Power failure memory
memo
No 76
Hysteresis (See note 1)
hys
Yes 78
Comparative output pattern (See note 1)
cĆout
Yes 80
H linear output range (See note 1)
lset.h
Yes
83
L Linear output range (See note 1)
lset.l
Yes
Remote/Local programming (See note 1)
rĆl
Yes 86
Note 1. The availability of the parameters depends on the type of selected Output
Board.
2. The selected bank number will be displayed where an asterisk (*) appears.
Available Functions
Flow Rate Ratio: f5
Section 3-5
