Connecting to the RS-232C Port at the Host Section 4-1
Note After connecting a communications cable, always secure it with the screws.
OMRON Cables with Connectors
When a connection is made at serial port A in other than the memory link
method, OMRON cables with connectors shown below are available.
When a connection is made to a personal computer at serial port A in the
memory link method, OMRON cable with connectors shown below are avail-
able.
When a connection is made at serial port B in other than the memory link
method, OMRON cables with connectors shown are available.
Note The cable’s tensile load is 30 N. Do not subject it to loads greater than this.
Connector
hood
XM2S-0911 9-pin
Made by OMRON
C-series CQM1, C200HS,
C200HX/HG/HE-(Z)E,
CVM1/CV-series CPU
Units
CV500-LK201
XM2S-0913 9-pin
Made by OMRON
XM2S-0911-E 9-pin
Made by OMRON
CS-series CS1G/CS1H/
CS1D
CJ-series CJ1G/CJ1H/
CJ1M
XM2S-2511 25-pin
Made by OMRON
C500-LK203
CV500-LK201
C200H-LK201-EV1
DB-C2-J9 25-pin
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
Cable AWG28×5P
IFVV-SB
Multi-core shielded cable
Made by Fujikura, Ltd.
CO-MA-VV-SB
5P×28AWG
Multi-core shielded cable
Made by Hitachi Cable,
Ltd.
Name Model Remarks Delivered with
Model Cable Length Connector Specification
XW2Z-200S 2 m 9-pin ⇔ 25 pin
XW2Z-500S 5 m
XW2Z-200T 2 m 9-pin ⇔ 9-pin
XW2Z-500T 5 m
Model Cable Length Connector Specification
CV500-CN228 2 m 9-pin ⇔ 25 pin
XW2Z-S002 2 m 9-pin ⇔ 9 pin
Model Cable Length Connector Specification
XW2Z-200P 2 m 25-pin ⇔ 25 pin
XW2Z-500P 5 m
XW2Z-200S 2 m 25-pin ⇔ 9-pin
XW2Z-500S 5 m
