323
Image and Library Data
Section 7-5
S Procedure for creating and using library data
The procedure for creating library data and registering them on a screen is de-
scribed briefly here. For details, refer to the Operation Manual of the Support
Tool.
"
"
"
"
"
"
Call the library editor.
Specify the library code.
Create the library data.
Specify a range.
Exit the library editor and register the library data.
Screen editing.
Register the created library data for display.
[Restrictions]
S A maximum of 12,288 library data can be created for one screen data file: each
of the library data is assigned any required code within the range 1000 to 3FFF
H
(image/library code range) so that it can be managed and specified.
S A total of up to 256 of the following elements can be registered on one screen.
(Same for window screen.) For an overlapping screen comprising 8 child
screens, the maximum is also 256.
Image data, library data
S The maximum number of elements that can be registered for one library data is
64.
S The elements that can be registered in library data are the following fixed display
elements: other elements cannot be registered.
Text, circles, arcs, sectors, polylines, polygons, rectangles, tiling, marks.
S The codes used for library data are dedicated for image/library data use.
Library data cannot be included in character strings in the same way that marks
can.
S Library data that projects out of the screen area cannot be specified.
