373
Graphs
Section 7-10
[Common Attributes]
The relationship between the properties of a bar graph and the display results is
indicated below.
S Properties
General
Position Coordinates of the top left corner of the bar graph area.
Size Width and height of the area in which the bar graph is displayed
(dot units)
Width: 2 to 230 Height: 2 to 240
Frame Whether or not a frame is displayed for the graph area
Check mark (frame displayed)/
No check mark (frame not displayed)
Display Sign Whether or not a negative area is displayed.
Check mark (displayed)/No check mark (not displayed)
Direction Direction in which the bar graph extends (“Incremental Direction of
Bar Graphs”, page 375)
Up/Down/Left/Right
Color
Frame Display color of the frame (colors other than black and white fea-
tured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
+ Range Display color of the positive range (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
− Range Display color of the negative range (colors other than black and
white featured with NT31C only) (effective only when a check
mark is set for “Display Sign”)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Settings
Value
Table Entry Number of numeral memory table whose contents are to be dis-
played.
Display % Presence/absence of a percentage indication of the contents of
the numeral memory table (“Method for calculating the percentage
value”, page 375)
Check mark (percentage displayed)/
No check mark (no percentage display)
For details on the “Display %” property, refer to 7-4-2 “Text (Fixed
Display)” (page 310).
*2
100%
*1
(Specify 100% value using either of “Table Entry” or “Value”.)
Table Entry Numeral memory table number checked to find the 100% value
for percentage calculations
Designate the number of the numeral memory table that
stores the 100% value.
Range: 0 to 1999
Value Checked to find the 100% value for percentage calculations
Designate the 100% value (default: 100)
Range: −2147483648 to 2147483647
Reference - It is not possible to specify a character attribute and transparent background for
a percentage display.
- It is possible to specify a double width font type for a percentage display.
To Next Page
