378
Graphs
Section 7-10
[Common Attributes]
The relationship between the properties of an analogue meter and the display re-
sults is indicated below.
S Property
General
Position Coordinates of the top left corner of the analogue meter area.
Coordinate of the center position of the meter part of an
analogue meter.
Size Radius
10
Frame Whether or not a frame is displayed for the graph area.
Check mark (frame displayed)/
No check mark (frame not displayed)
Display color of the frame (colors other than black and white
featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Display Sign Whether or not a negative area is displayed.
Check mark (displayed)/ No check mark (not displayed)
Direction Direction in which the value extends ( “Incremental direction of
analogue meters”, page381)
Clock–wise/Anti–Clockwise
Shape Quarter/Semi–Circle/Circle
Direction Direction in which the analogue meter extends from 0% position
Type Display method of the area between present value and 0%
value.
Needle/Fill
Width Rate Meter width
10
Scale Display
Scale Whether or not a scale is displayed
Check mark (scale displayed)/
No check mark (scale not displayed)
Distance Position of the scale
0
100%=On circumference of the meter part
Scale
Length
Scale length
10 10% (regarding the radius as 100%)
100%=Same length as the radius of the meter part
No. of
Division
Number of the division which the scale should be divided
1
Scale
Colour
Scale color (colors other than black and white featured with
NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
To Next Page
