Omron NT31 User Manual

379
Graphs
Section 7-10
Meter Colour
Foreground Foreground color for the present value (needle or fill) of the
meter part (colors other than black and white featured with
NT31C only)
Black/Blue/Red Magenta/Green/Cyan/Yellow/White
Background Background color of the analogue meter (colors other than black
and white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
+Range Display color for the positive range (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
–Range Display color for the negative range (colors other than black and
white featured with NT31C only) (effective only when a check
mark is set for ”Display Sign”)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Settings
Value
Table Entry Number of numeral memory table whose contents are to be
displayed.
Display % Presence/absence of a percentage indication of the contents of
the numeral memory table (“Method for calculating the
percentage value”, page382)
Check mark (percentage displayed)/
No check mark (no percentage displayed)
For details on the “Display %” property, refer to 7-4-2 “Text
(Fixed Display)” (page 310)
100% *1 (Specify 100% value using either of “Table Entry” or “Value”.)
Table Entry Numeral memory table number check to find the 100% value for
percentage calculation
Designate the number of the numeral memory table
that
stores the 100% value.
Value Check to find the 100% value for percentage calculation
Designate the 100% value (default: 100)
0% *1 (Specify 0% value using either of “Table Entry” or “Value”.)
Table Entry Numeral memory table number check to find the 0% value for
percentage calculation
Designate the number of the numeral memory table
that
stores the 0% value.
Value Check to find the 0% value for percentage calculation
Designate the 0% value (default: 0)
-100% *1 (Specify -100% value using either of “Table Entry” or “Value”.)
Table Entry Numeral memory table number check to find the –100% value
for percentage calculation
Designate the number of the numeral memory table
that
stores the –100% value.
Value Check to find the –100% value for percentage calculation
Designate the –100% value (default: –100)
