426
Inputting Numeric Values
Section 7-12
S It is not possible to set input from more than one numeral setting input field (nu-
meric key type or thumbwheel type) on the same screen to one numeral memory
table.
In cases where values at the host must be input both in decimal and hexadeci-
mal, set numeral input into separate numeral memory tables, both allocated to
the same area.
S The range of numeric values that can be input depends on the Storage Type”
(“BCD” or “Binary”) of the numeral memory table, and the “Display Type” (“Deci-
mal” or “Hexadecimal”), and “Display Sign” settings made for the numeral set-
ting input field. For details, refer to 7-3-1 Numeral Memory Tables (page 284).
S It is not possibleto register multiple input fields (regardless of the type of numeric
key or thumbwheel) which refer to the same numeral table entry on the same
screen.
[Common Attributes]
The relationship between the properties of a thumbwheel type numeral setting in-
put field and the numeric values input and displayed is indicated below.
S Properties
General
Position Coordinates of the top left corner of the numeral setting input
field
Size Size of the input field
Small/Medium/Large
End Plate Presence/absence of end plates at either end of the numeral
setting input field
Check mark (end plates used)/
No check mark (end plates not used)
Attribute Display mode for the numerals (“Display attributes and
drawing result”, page 359)
Standard/Flash/Inverse Flash
Thumbwheel Color
Frame Color of the frame of the numeral setting input field (colors
other than black and white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Foreground Foreground color of the numeral setting input field (colors
other than black and white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numeral setting input field (colors
other than black and white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Character Color
Foreground Display color of the numerals (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numerals (colors other than black
and white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
