Commands/Responses
Section 9-3
9-3-9 Character string memory table write command
(Sent from host to PT)
Command
[Format]
m
1B 57
[ESC] W t3 t4
53
St1
d11 d12
t2
0D
dn1 dn2
(s1) (s2) [CR]
** ** ** ** **
** ** ** ** ** **
m : Check sum present/absent (1 BCD digit)
0 : Absent
1 :Present
t
1
to t
4
: Character string memory number written to (4 BCD digits)
0000 to 0499
d1
1
,d1
2
, ..., dn
1
,dn
2
:
Contents of the written character string memory tables
(1 to 40 characters)
00 to FF
H
In the case of character string memory tables allocated to the
host, specify the registered number of words multiplied by 2, and
in the case of character string memory tables not allocated to the
host, specify the data for 40 characters.
s
1
,s
2
: Check sum (2 hexadecimal digits)
When m is 0, omit this setting.
Reference:
The maximum number which can be specified for character string memory table
depends on the setting for numbers of character string table entries
(256/1000/2000) made at the Support Tool. However, it is not possible to write to
character string memory table of numbers higher than No.500 sincethey areused
only as a reading area.
Response
Only if “Yes” is set for the “Response” memory switch, the response indicated be-
low is returned on normal completion.
[Format]
1B 57
[ESC] [CR]W
3530 32 0D53
S
30
0 0 s1 s2
s
1
,s
2
: Check sum (2 hexadecimal digits)
This is always added (fixed as “25H”).
[Function]
S Writes specified data to the specified character string memory tables.
