Omron NT31 - Page 597

586
Commands/Responses
Section 9-3
9-3 -13 Character string memory table clear command
(Sent from host to PT)
Command
[Format]
m
1B 43
[ESC] C
(e3)
(b3)
(e4)
53
S (b1) (b2)
0D
(b4)
(e1)
(e2)
(s1) (s2) [CR]
** ** ** ** **
** ** ** ** ** **
m : Check sum present/absent (1 BCD digit)
0 : Absent
1 : Present
b
1
to b
4
: First cleared character string memory table number
(4 BCD digits)
0000 to 0499
e
1
to e
4
: Final cleared character string memory table number
(4 BCD digits)
0000 to 0499
s
1
,s
2
: Check sum (2 hexadecimal digits)
When m is 0, omit this setting.
Reference:
The maximum number which can be specified for character string memory table
depends on the setting for numbers of character string table entries
(256/1000/2000) made at the Support Tool. However, it is not possible to clear
character string memory table of numbers higher than No.500.
Response
Only if “Yes” is set for the “Response” memory switch, the response indicated be-
low is returned on normal completion.
[Format]
1B 43
[ESC] [CR]C
3130 31 0D53
S
30
0 0 s1 s2
s
1
,s
2
: Check sum (2 hexadecimal digits)
This is always added (fixed as “11H”).
[Function]
S Writes 40 characters of space code (20H) to all the character string memory
tables within the specified range.
S If settings are omitted for both the “first cleared character string memory table
number” and the “final cleared character string memory table number”, all the
character string memory tables are cleared. It is not possible to omit just one of
these settings.
