588
Commands/Responses
Section 9-3
9-3-15 Touch switch input notify command
(Sent from PT to host)
Command
[Format]
c1
1B 53
[ESC] S
d4
c4
54
Tc2c3
0D
d1 d2
d3 a4a1 a2 a3 s1 s2 [CR]
** ** ** ** ** **
** ** ** ** ** ** ** **
c
1
to c
4
: Changed word number (4 BCD digits)
0000 to 9999
This is the number of the word containing the allocated bit of the
touch switch at which there has been a change.
d
1
to d
4
: Contents of the word after the change (4 hexadecimal digits)
0000 to FFFF
H
a
1
to a
4
: Changed bit information (4 hexadecimal digits)
0000 to FFFF
H
The changed bit in the “contents of the word after the change” is
set to “1”.
s
1
,s
2
: Check sum (2 hexadecimal digits)
This is always added.
Response
[Format]
None
[Function]
S When the status of a touch switch changes because it has been touched or re-
leased, notifies the change of status to the host.
S Normally, one command notifies the change in status of one allocated bit only,
but when multiple bits in the same word change simultaneously, those changes
are all notified together with one command.
Reference:
When the screen is switched after pressing a “momentary” key, this command
goes OFF. The change is also notified to the host.
