678
Model List
APPENDIX J
CPUs (For Connection via an NT Link (1:N))
Model Specification PC Type
C200HE-CPU32-(Z)E
(*)
C200HE-CPU42-(Z)E
Features a connector for RS-232C connections (selectable/9-pin) C-series
C200HE(-ZE)
C200HG-CPU34-(Z)E
(*)
C200HG-CPU43-(Z)E
C200HG-CPU53-(Z)E
(*)
C200HG-CPU63-(Z)E
Features a connector for RS-232C connections (selectable/9-pin) C-series
C200HG(-ZE)
C200HX-CPU34-(Z)E
(*)
C200HX-CPU44-(Z)E
C200HX-CPU54-(Z)E
(*)
C200HX-CPU64-(Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
Features a connector for RS-232C connections (selectable/9-pin) C-series
C200HX(-ZE)
CS1G-CPU42-E
CS1G-CPU43-E
CS1G-CPU44-E
CS1G-CPU45-E
Features a connector for RS-232C connections (9-pin) CS1-series
CS1G
CS1H-CPU63-E
CS1H-CPU64-E
CS1H-CPU65-E
CS1H-CPU66-E
CS1H-CPU67-E
Features a connector for RS-232C connections (9-pin) CS1-series
CS1H
* Either of the communication boards C200HW-COM02/COM04/COM05/COM06-V1 is required.
RS-232C/RS-422A Convertor Unit
Model Specification
NT-AL001 RS-232C: 9-pin connector
RS-422A: 8-pin terminal block
RS-232C Adaptor, RS-422A Adaptor
Model Specification
CPM1-CIF01 Links the RS-232C port of an NT31/NT31C and the peripheral
port of a CPM1 (compatible with host link, and NT link (1:1))
CPM1-CIF11 Links the RS-422A port of an NT31/NT31C and the peripheral
port of a CPM1 (compatible with host link)
