Model List
APPENDIX J
Related Parts and Equipment for PT
Name Model Remark
Support Tool*
NT-ZJ3M
Compatible with PC/AT personal computers
For Windows95/98 (English version)
3.5 inch FD
NT-ZJCM1-EV3
Compatible with PC/AT personal computers
For Windows95/98 (English version)
CD–ROM
Options NT31C-CFL01 Replaceable backlight (common to NT31 and NT31C)
NT30-KBA04 Reflection suppressing protective sheet for NT31/NT31C
NT30-KBA01 Chemical–resistant cover for NT31/NT31C
NT-MF261 Memory unit for NT31/NT31C
3G2A9-BAT08 Spare battery
* The Support Tool indicated above includes the system installer and the standard system programs for the NT31, NT31C,
NT631, and NT631C.
Cables with Connectors (PT ↔ PLC/NT-AL001)
Model Cable Length Applicable units Communication Method Specification
XW2Z-200S 2 m Host link units with a 25-pin Serial port A host link
↔
XW2Z-500S 5 m
connector
(RS-232C only)
9-pin ↔ 25-pin
XW2Z-200T 2 m Host link units with a 9-pin Serial port A host link, NT link (1:1)
↔
XW2Z-500T 5 m
connector
(RS-232C only)
9-pin ↔ 9-pin
XW2Z-200P 2 m Host link units with a 25-pin Serial port B host link
↔
XW2Z-500P 5 m
connector
(RS-232C only)
25-pin ↔ 25-pin
XW2Z-200S 2 m Host link units with a 9-pin Serial port B host link, NT link (1:1)
↔
XW2Z-500S 5 m
connector (RS-232C only)
25-pin ↔ 9-pin
XW2Z-S002 2 m Personal computer with a 9-pin
connector
Serial port A for using NT Support
Tool
9-pin ↔ 9-pin
*1 Only the PLC C200HX/HG/HE (-Z) and CSI-Series can supply +5V
Cables with Connectors
Model Cable Length Specification
CV500-CN228 2 m 25-pin (male) ↔ 9-pin (male)
XW2Z-S002 2 m 9-pin (female) ↔ 9-pin (male)
Connection Cable
Model Specification
AWG28 5P IFVV-SB Multicore cable, manufactured by Fujikura, Ltd.
CO-MA-VV-SB 5P 28AWG Multicore cable, manufactured by Hitachi Cable, Ltd.
