Connecting to the RS-232C Port at the Host
Section 4-1
S Connecting to CVM1/CV series (-EVj)
Set the DIP switches on the front panel as follows.
OFF
ON
1
2
3
4
5
6
ON
I/O port selection (selector switch)
Set this to “RS-232C”.
Set SW3 to “use NT link”
(“ON”, right side).
DIP switch setting (SW3)
When using the CVM1/CV series, “CPU execution processing (execution con-
trol 2)” in the PC system settings must be set to “Simultaneous processing”.
