88
Connecting to the RS-232C Port at the Host
Section 4-1
When Using the Memory Link Method
In the memory link method, the connection can be made to a personal computer
with RS-232 and an FA computer, etc.
When connecting to the host in the memory link method, it is necessary to create a
program for the memory link at the host side.
The following are the communication conditions that can be used in the memory
link method. For the host (a personal computer, an FA computer, etc.), its setting
should be compatible to one of the communication conditions listed in the following
table. Set the same communication conditions at the NT31/NT31C by the memory
switch. (page 181).
Item Settings at the host
Input/Output port RS-232C
Communication speed 1200, 2400, 4800, 9600, 19200, 38400 bps.
Data bits length 7 bits, 8 bits
Stop bits length 1 bits, 2 bits
Parity None, even, odd
Flow control None, RS/CS, XON/XOFF
To Next Page
