Omron NX Series Reference Manual

1 - 5
1 Data List
NX-series Data Reference Manual (W525)
1-2 CPU Units
1
1-2-1 NX1P2 CPU Units
1-2 CPU Units
This section describes the data for CPU Units.
 Items in the Summary Specifications
 Data List
1-2-1 NX1P2 CPU Units
Item Description
Unit power supply Rated voltage The rated voltage of the Unit power supply that is supplied to the Unit.
NX Unit power supply capacity The amount of power that the Unit can supply to the NX Units.
Model
Unit configuration data Summary specifications
Unit power
consump-
tion [W]
*1
*1. The power consumption of an SD Memory Card and Option Boards are included. The power consumption of
NX Units from the NX Unit power supply is not included.
Weight [g]
*2
*2. The weight of the End Cover is included.
Width
[mm]
*2
Unit power sup-
ply
NX Unit power
supply capac-
ity
*3
*3. The NX Unit power supply capacity is not restricted by the ambient operating temperature, installation
orientation, or other conditions.
Rated voltage
NX1P2-1040DT 7.05 650 154 24 VDC 10 W max.
NX1P2-1040DT1 6.85 660
NX1P2-1140DT 7.05 650
NX1P2-1140DT1 6.85 660
NX1P2-9024DT 6.70 590 130
NX1P2-9024DT1 6.40

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
