Omron NX Series Reference Manual

Appendices
A - 16
NX-series Data Reference Manual (W525)
The following indicates the Screwless Clamping Terminal Blocks that are applicable to each Unit.
A-4-3 Applicable Screwless Clamping Terminal Blocks for Each Unit
Model
Unit model num-
ber
Terminal Block
Model
Number of
terminals
Ground terminal
mark
Current capacity
NX-ECC201 NX-TBA081 8 Not provided 4 A
NX-TBC082 Provided 10 A
NX-ECC202 NX-TBC082 10 A
NX-EIC202 NX-TBC082 8 Provided 10 A
NX-ID3 NX-TBA121 12 Not provided 4 A
NX-TBA122 10 A
NX-ID4 NX-TBA161 16 4 A
NX-TBA162 10 A
NX-ID5 NX-TBA161 4 A
NX-TBA162 10 A
NX-IA3117 NX-TBA081 8 4 A
NX-TBA082 10 A
NX-OD2 NX-TBA081 4 A
NX-TBA082 10 A
NX-OD3268 NX-TBA162 16 10 A
NX-OD3
(any model other
than NX-OD3268)
NX-TBA121 12 4 A
NX-TBA122 10 A
NX-OD4 NX-TBA161 16 4 A
NX-TBA162 10 A
NX-OD5 NX-TBA161 4 A
NX-TBA162 10 A
NX-OC2 NX-TBA081 8 4 A
NX-TBA082 10 A
NX-OC4633 NX-TBA082 10 A
NX-TBB082
NX-AD2 NX-TBA081 4 A
NX-TBA082 10 A
NX-AD3 NX-TBA121 12 4 A
NX-TBA122 10 A
NX-AD4 NX-TBA161 16 4 A
NX-TBA162 10 A
NX-DA2 NX-TBA081 8 4 A
NX-TBA082 10 A
NX-DA3 NX-TBA121 12 4 A
NX-TBA122 10 A
NX-TS21 You cannot replace the Terminal Blocks.
Refer to the NX-series Analog I/O Units User’s Manual (Cat. No. W522) for details.
NX-TS31

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
