1 - 37
1 Data List
NX-series Data Reference Manual (W525)
1-10 Temperature Control Units
1
1-10 Temperature Control Units
This section describes the data for Temperature Contorol Units.
Items in the Summary Specifications
Item Description
Number of channels,
Input type,
Conversion time
• Number of channels
The number of control loops that are provided on the Unit.
*1
• Input type
The input type of the temperature input that are provided on the Unit.
In the following table, the following abbreviations are used.
Universal: Thermocouple and Platinum resistance thermometer
• Conversion time
The time required to convert temperature input signals of the Unit to temperature data.
*1. One temperature input is provided for each channel. For example, the Unit with two channels has two inputs.
Output Output type The control outputs that are provided by the Unit.
In the following table, the following abbreviation is used.
Voltage: Voltage output (for driving SSR)
Current: Linear current output
Number of out-
put points per
channel
The number of output points per channel on the Unit.
Number of CT input points per
channel
The number of CT inputs per channel on the Unit.
Control type The control types that are provided by the Unit.
In the following table, the following abbreviation is used.
Standard: Standard control
Heating/cooling: Heating/cooling control
I/O refreshing method The I/O refreshing methods that are used by the Unit.
Only Free-Run refreshing is available.
In the following table, the following abbreviation is used.
Free: Free-Run refreshing
To Next Page
