NX-series Data Reference Manual (W525)
1-6 Position Interface Units
This section describes the data for Position Interface Units.
 Items in the Summary Specifications
 Data List
1-6-1 Incremental Encoder Input Units
Item Description
Number of channels The number of encoder input channels of the Unit.
Number of external
inputs
The number of external inputs of the Unit.
Maximum response
frequency
The maximum frequency of the encoder input.
I/O refreshing method The I/O refreshing methods that are used by the Unit.
Free-Run refreshing, synchronous I/O refreshing and task period prioritized refreshing are avail-
able.
In the following table, the following abbreviations are used.
Free
: Free-Run refreshing
Sync
: Switching synchronous I/O refreshing and Free-Run refreshing
Task: Switching Free-Run refreshing, synchronous I/O refreshing and task period prioritized
refreshing
Model
Unit configuration data Summary specifications
NX Unit
power
consump-
tion [W]
Current
consump-
tion from
I/O power
supply
[mA]
I/O
power
supply
method
Weig
ht
[g]
Widt
h
[mm]
I/O
data
size
[byte]
Num-
ber of
I/O
entry
map-
pings
Number
of
channel
s
Number
of exter-
nal
inputs
Maxi-
mum
respons
e fre-
quency
I/O
refresh
ing
metho
d
Remar
ks
CPU
Cou-
pler
NX-EC0112 1.15 0.85 0 NX bus 70 12 18/4 1/1 1 (NPN) 3 (NPN) 500 kHz Sync or
Tas k
*1
*1. "Sync" is for Units with unit version 1.1 or earlier. "Task" is for Units with unit version 1.2 or later.
24 V
voltage
input
NX-EC0122
1.30 0.95 1 (PNP) 3 (PNP)
NX-EC0132 1.25 0.95
30
*2
*2. When you use the 5-V power supply for an encoder, be sure to include that current too. Refer to the NX-series Position
Interface Units User's Manual (Cat. No. W524-E1-04 or later) for information on how to convert a 5-V power supply current
consumption to a 24-V power supply current consumption.
130 24 18/4 1/1 1 3 (NPN) 4 MHz Line
receive
r input
NX-EC0142
1.50 1.05 3 (PNP)
NX-EC0212 1.15 0.85 0 70 12 36/8 2/2 2 (NPN) None 500 kHz 24 V
voltage
input
NX-EC0222
1.30 0.95 2 (PNP)

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
