Omron NX Series Reference Manual

1 Data List
1 - 42
NX-series Data Reference Manual (W525)
 Items in the Summary Specifications
 Data List
1-12-2 Safety Input Units
Item Description
Number of safety
input points
This is the number of safety input points on the Unit.
Number of test output
points
This is the number of test output points on the Unit. The test output points are used with the safety
input terminals.
Internal I/O common This is the polarity that the Unit uses to connect to input devices. There are
models with NPN and PNP connections.
Rated input voltage This is the rated input voltage of the Unit.
OMRON Special
Safety Input Devices
This tells whether the Unit supports the connection of OMRON Special Safety Input Devices (D40A
Non-contact Door Switches, E3FS Single Beam Safety Sensors, etc.).
In the following table, the following abbreviations are used.
Yes: Can be connected
No: Cannot be connected
Number of safety
slave connections
This is the number of safety slave connections that the Unit can have through Safety over Ether-
CAT (FSoE). You can connect to one Safety CPU Unit for each safety slave connection.
I/O refreshing method The I/O refreshing methods that are used by the Unit.
Only Free-Run refreshing is available.
In the following table, the following abbreviation is used.
Free: Free-Run refreshing
Model
Unit configuration data Summary specifications
NX Unit
power
consump-
tion [W]
Curre
nt
consu
mptio
n from
I/O
power
supply
[mA]
Input
cur-
rent
[mA]
I/O
powe
r sup-
ply
meth
od
Wei
ght
[g]
Width
[mm]
I/O
data
size
[byte]
Num-
ber of
I/O
entry
map-
pings
Numb
er of
safety
input
point
s
Numb
er of
test
outpu
t
point
s
Intern
al I/O
comm
on
Rated
input
voltag
e
OMR
ON
Speci
al
Safet
y
Input
Devic
es
Numb
er of
safety
slave
conne
ctions
I/O
refres
hing
metho
d
CPU
Cou-
pler
NX-SID800 --- 0.75 20 3.0 NX
bus
70 12 10/
10
2/2 8
point
s
2
point
s
PNP 24
VDC
No 1 Free
NX-SIH400 0.70 4.5 8/8 4
point
s
Yes
