Omron NX Series Reference Manual

A - 17
Appendices
NX-series Data Reference Manual (W525)
A-4 List of Screwless Clamping Terminal
Block Models
A
A-4-3 Applicable Screwless Clamping Terminal Blocks for Each Unit Model
NX-TS22 NX-TBA161 16 Not provided 4 A
NX-TBA162 10 A
NX-TS32 NX-TBA161/TBB161 4 A
NX-TBA162/TBB162 10 A
NX-HB301 NX-TBA161 4 A
NX-TBA162 10 A
NX-EC0112 NX-TBA161 4 A
NX-TBA162 10 A
NX-EC0122 NX-TBA161 16 Not provided 4 A
NX-TBA162 10 A
NX-EC0132 NX-TBA121/TBB121 12 Not provided 4 A
NX-TBA122/TBB122 10 A
NX-EC0142 NX-TBA121/TBB121 4 A
NX-TBA122/TBB122 10 A
NX-EC0212 NX-TBA121 4 A
NX-TBA122 10 A
NX-EC0222 NX-TBA121 4 A
NX-TBA122 10 A
NX-ECS112 NX-TBA121 4 A
NX-TBA122 10 A
NX-ECS212 NX-TBA121 4 A
NX-TBA122 10 A
NX-PG0112 NX-TBA161 16 4 A
NX-TBA162 10 A
NX-PG0122 NX-TBA161 4 A
NX-TBA162 10 A
NX-CIF101 NX-TBC162 Provided 10 A
NX-CIF105 NX-TBC162 10 A
NX-RS1201 NX-TBC162 10 A
NX-ILM400 NX-TBA162 Not provided 10 A
NX-TC4 The terminal block can not be replaced.
Refer to the NX-series Temperature Control Units User's Manual (Cat. No. H228) for
details.
NX-PD1000 NX-TBA081 8 Not provided 4 A
NX-TBC082 Provided 10 A
NX-PF0630 NX-TBA081 Not provided 4 A
NX-TBA082 10 A
NX-PF0730 NX-TBA082 10 A
NX-PC NX-TBA161 16 4 A
NX-TBA162 10 A
NX-TBX01 NX-TBA161 4 A
NX-TBC162 Provided 10 A
NX-SL3300 No Terminal Blocks
NX-SL3500 No Terminal Blocks
Unit model num-
ber
Terminal Block
Model
Number of
terminals
Ground terminal
mark
Current capacity
