Appendices
A - 18
NX-series Data Reference Manual (W525)
Precautions for Correct Use
You can mount NX-TB1 and NX-TB2 Terminal Blocks to the Units whose terminal
current capacity is specified to 4 A or less.
However, even if you mount the NX-TB2 Terminal Block, the current specification does
not change because the current capacity specification of the terminals on the Units is 4 A or
less.
NX-SIH400 NX-TBA081 8 Not provided 4 A
NX-TBA082 10 A
NX-SID800 NX-TBA161 16 4 A
NX-TBA162 10 A
NX-SOD400 NX-TBA081 8 4 A
NX-TBA082 10 A
NX-SOH200 NX-TBA081 4 A
NX-TBA082 10 A
Unit model num-
ber
Terminal Block
Model
Number of
terminals
Ground terminal
mark
Current capacity
