1 Data List
NX-series Data Reference Manual (W525)
1-6 Position Interface Units
1
1-6-3 Pulse Output Units
Items in the Summary Specifications
Data List
Pulse Output Units (MIL Connector, 30 mm Width)
Item Description
Number of channels The number of pulse output channels of the Unit.
Number of external
inputs
The number of external inputs of the Unit. The number of inputs for each pulse output channel.
Number of external
outputs
The number of external outputs of the Unit. The number of outputs for each pulse output channel.
Maximum pulse out-
put speed
The maximum pulse output speed.
I/O refreshing method The I/O refreshing methods that are used by the Unit.
Synchronous I/O refreshing and task period prioritized refreshing are available.
In the following table, the following abbreviations are used.
Sync: Synchronous I/O refreshing
Task: Switching synchronous I/O refreshing and task period prioritized refreshing
*1
*1. For Pulse Output Units, Free-Run refreshing is not available.
Model
Unit configuration data Summary specifications
NX Unit
power
consump-
tion [W]
Current
consump-
tion from
I/O power
supply
[mA]
I/O
pow
er
sup-
ply
met
hod
Weig
ht
[g]
Widt
h
[mm]
I/O
data
size
[byte
]
Num-
ber of
I/O
entry
map-
pings
Numb
er of
chann
els
Numb
er of
exter-
nal
inputs
Numb
er of
exter-
nal
out-
puts
Maxi-
mum
pulse
out-
put
speed
I/O
refresh
ing
metho
d
Remar
ks
CPU
Cou-
pler
NX-PG0232-5
1.55 1.20 50 Exter
nal
110 30 34/26 2/2 2 5
inputs
per
chan-
nel
(NPN)
3
inputs
per
chan-
nel
(NPN)
4Mpp
s
Tas k
Line
driver
output
NX-PG0242-5
1.20 50 110 5
inputs
per
chan-
nel
(PNP)
3
inputs
per
chan-
nel
(PNP)
NX-PG0332-5
1.65 1.30
50/CN
*1
*1. The current consumption from I/O power supply for one MIL connector.
150 68/52 4/4 4 5
inputs
per
chan-
nel
(NPN)
3
inputs
per
chan-
nel
(NPN)
NX-PG0342-5
1.30
50/CN
*1
150 5
inputs
per
chan-
nel
(PNP)
3
inputs
per
chan-
nel
(PNP)
To Next Page
