Omron NX Series Reference Manual

Appendices
A - 8
NX-series Data Reference Manual (W525)
 Output Delay Time of NX Unit (Tnx-Outdelay)
Pulse Output Units NX-PG0122
/-PG0112
0 [μs] This is the value for external inputs.
The ON/OFF response time of the
external inputs is included in
Tnx-InProc.
NX-PG0232-5
/-PG0242-5
/-PG0332-5
/-PG0342-5
0 [µs] The value for external inputs 0 and
1. The ON/OFF response time of
external inputs 0 and 1 is included in
Tnx-InProc.
*2
ON/OFF
response time
This is applicable to external inputs 2
through 4.
Load Cell Input Unit NX-RS1201 0 [µs] −
*1. If only a definition is given in the above table, refer to the data of the NX Units in Section 1 Data List or the
manuals for the specific NX Units for the values of the items.
*2. The value for external input 0 is the same as one given in the above table even if it is used in the model
with a line receiver input.
NX Units
Tnx-Outdelay
*1
*1. If only a definition is given in the above table, refer to the data of the NX Units in Section 1 Data List or the
manuals for the specific NX Units for the values of the items.
Remarks
Type Model
Digital Output Units Models support synchro-
nous I/O refreshing
ON/OFF
response time
The ON/OFF response time
depends on the model of the Unit.
Digital Mixed I/O Units ON/OFF
response time
This is applicable to the digital out-
puts.
The ON/OFF response time
depends on the model of the Unit.
Analog Output Units 0 [μs] −
Pulse Output Units NX-PG0122
/-PG0112
0 [μs] The value for pulse outputs and
external outputs. The ON/OFF
response time of the external out-
puts is included in Tnx-OutProc.
NX-PG0232-5
/-PG0332-5
0 [µs] The value for pulse outputs and
external output 0. The ON/OFF
response time of external output 0 is
included in Tnx-OutProc.
ON/OFF
response time
This is applicable to external outputs
1 and 2.
NX-PG0242-5
/-PG0342-5
0 [µs] The value for pulse outputs.
ON/OFF
response time
This is applicable to external out-
puts. The ON/OFF response time
depends on the output port.
NX Units
Tnx-Indelay
*1
Remarks
Type Model

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
