Omron NX1P2 series User Manual

3 - 35
3 Configuration Units
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
3-7 Sysmac Studio
3
3-7-2 Connection
Additional Information
The Sysmac Studio cannot connect online to an NJ/NX-series CPU Unit in the following type of
configuration.
• If the built-in EtherNet/IP port is not used, you cannot connect to an NJ/NX-series CPU Unit
on an EtherNet/IP network.
Example: Connection to NJ/NX-series CPU Unit Routing through an EtherNet/IP Unit or Built-in
Port
• You cannot route through any networks other than EtherNet/IP networks.
Sysmac Studio
USB
EtherNet/IP
CS1W-EIP21, CJ1W-EIP21,
CJ2 built-in EtherNet/IP port,
CJ2M built-in EtherNet/IP port

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
