Omron NX1P2 series

Appendices
A - 4
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
*1. The dimension from the attachment surface of the DIN Track to the front surface of the CPU Unit.
A-2-2 End Cover
NX1W-END02
A-2-3 SD Memory Card
Unit: [mm]
65.2
*1
71
6
100
1.5 1.5
2.1 ± 0.15
32
± 0.1
24
± 0.1
