Omron NX1P2 series User Manual

3 Configuration Units
3 - 2
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
3-1 CPU Units
This section describes the models and specifications of the CPU Units as well as the names and func-
tions of the parts.
This section describes the outline of the CPU Unit specifications. The electrical and mechanical
specifications of the CPU Unit are also given. Refer to 1-2 Specifications on page 1-8 for information on
other main specifications.
The models and outline of specifications are given below.
3-1-1 Models and Specifications
Models and Outline of Specifications
Model
Program
capacity
Memory capacity
for variables
Maxi-
mum
num-
ber of
con-
trolled
axes
Built-in I/O
Total
number
of I/O
points
Number
of input
points
Number of out-
put points
NX1P2-1140DT 1.5 MB 32 KB (Retained
during power inter-
ruptions)
or 2 MB (Not retained
during power inter-
ruptions)
12
axes
40 points 24 points 16 points, NPN
transistor
NX1P2-1140DT1 16 points, PNP
transistor
*1
*1. With short-circuit protection
NX1P2-1040DT 10
axes
16 points, NPN
transistor
NX1P2-1040DT1 16 points, PNP
transistor
*1
NX1P2-9024DT 4 axes 24 points 14 points 10 points, NPN
transistor
NX1P2-9024DT1 10 points, PNP
transistor
*1

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
