Omron NX1P2 series User Manual

5 - 15
5 Installation and Wiring
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
5-3 Mounting Units
5
5-3-2 Preparations for Installation
 DIN Tracks
PFP-100N/50N DIN Track
NS 35/ 7,5 PERF
NS 35/ 15 PERF
 End Plate
PFP-M (Two)
CLIPFIX 35 (Two)
1,000 (500)
*1
15
10
4.5
25 25 25
10
25 15 (5)
*1
1
7.3±0.15
35
±0.3
27
±0.15
*1. PFP-50N dimensions are
given in parentheses.
1
7.5
35
27
R0.8
R0.8
6.2
15
25
1.5
0.8
15
35
27
R1.25
15
°
R1.25
6.2
15
25

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
