6 Troubleshooting
6 - 46
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Event name SD Memory Card Data Corrupted Event code 10060000 hex
Meaning A file that must be in the SD Memory Card is missing or corrupted.
Source PLC Function Module Source details None Detection
timing
At power ON or
Controller reset
Error attributes Level Observation Recovery --- Log category System
Effects User program Continues. Operation SD PWR indicator is not lit. You can format the SD Mem-
ory Card from the Sysmac Studio. Normal user program
operation may not be possible.
System-defined
variables
Variable Data type Name
_Card1Ready BOOL SD Memory Card Ready Flag
Cause and
correction
Assumed cause Correction Prevention
The Controller power supply was
turned OFF while the SD BUSY indi-
cator was lit.
Format the SD Memory Card and
download the correct file.
Do not turn OFF the power supply
while the SD BUSY indicator is lit.
The power supply to the Controller
was interrupted momentarily while the
SD BUSY indicator was lit.
Take appropriate measures to ensure
that the specified power with the rated
voltage and frequency is supplied in
places where the power supply is
unstable.
The SD Memory Card was removed
while the SD PWR indicator was lit.
Do not remove the SD Memory Card
while the SD PWR indicator is lit.
The SD Memory Card is damaged. If the error cannot be cleared with the
above corrections, replace the SD
Memory Card with one that operates
normally.
None
Attached
information
None
Precautions/
Remarks
The error is detected at power ON or at a Controller reset only when SD Memory Card diagnosis at startup is enabled.
You can change the event level to the minor fault level. If you change the level to the minor fault level, the Recovery
column above will be changed to “Error reset.”
