Page #286 background imageLoading...
Page #286 background image
6 Troubleshooting
6 - 68
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Event name SD Memory Card Program Transfer Pre-execution Check
Error
Event code
10330000 hex
Meaning An error was detected in pre-execution checks for transferring SD Memory Card programs.
Source PLC Function Module Source details None Detection
timing
Before SD Mem-
ory Card pro-
grams are
transferred after
a Controller reset
Error attributes Level Major fault Recovery Cycle the power-
supply or reset
the Controller.
Log category System
Effects User program Stops. Operation
Stops.
*1
System-defined
variables
Variable Data type Name
_Card1PrgTransferSta _sPRGTRANSFER_STA SD Memory Card Program Transfer
Status
Cause and
correction
Assumed cause Correction Prevention
An SD Memory Card is not inserted. Insert an SD Memory Card. Insert an SD Memory Card.
The SD Memory Card type is not cor-
rect.
Replace the SD Memory Card with an
SD or SDHC card.
Use an SD or SDHC card.
The format of the SD Memory Card is
not correct.
Format the SD Memory Card with the
Sysmac Studio, create a folder speci-
fied by the _Card1PrgTransfer-
Cmd.DirName system-defined
variable on the card, and store the
backup files in the folder.
Use a formatted SD Memory Card,
create a folder specified by the
_Card1PrgTransferCmd.DirName
system-defined variable on the card,
and store the backup files in the
folder.
Also, do not remove the SD Memory
Card or turn OFF the power supply
while the SD BUSY indicator is lit.
There is no such folder on the SD
Memory Card as specified by the
_Card1PrgTransferCmd.DirName
system-defined variable.
Create a folder specified by the
_Card1PrgTransferCmd.DirName
system-defined variable on the SD
Memory Card and store the backup
files in the folder.
There are no backup files in such a
folder on the SD Memory Card as
specified by the _Card1PrgTransfer-
Cmd.DirName system-defined vari-
able.
Either the backup files in the folder
specified by the _Card1PrgTransfer-
Cmd.DirName system-defined vari-
able on the SD Memory Card are
corrupted or required data is not in
the backup files on the SD Memory
Card.
Replace the backup files in the folder
specified by the _Card1PrgTransfer-
Cmd.DirName system-defined vari-
able.
If this error occurs again even after
replacing the files, create the backup
files again and place them in the
folder specified by the _Card1Prg-
TransferCmd.DirName system-
defined variable.
The unit version of the CPU Unit to
which to transfer the files is older than
the unit version of the backup files on
the SD Memory Card.
Replace the CPU Unit with a CPU
Unit that has a unit version that is the
same as or newer than the unit ver-
sion of the CPU that was used to cre-
ate the backup files.
Or, place the backup files with the
correct unit version for the CPU Unit,
in the folder specified by the
_Card1PrgTransferCmd.DirName
system-defined variable.
Make sure that the unit version of the
CPU Unit and the unit version of the
backup files are compatible.
