Omron NX1P2 series User Manual

6 Troubleshooting
6 - 76
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Attached
information
Attached information 1: Operation type
0101 hex: Controller to SD Memory Card for switch operation on front of CPU Unit
0102 hex: Controller to SD Memory Card for system variable operation
0103 hex: Controller to SD Memory Card for Sysmac Studio operation
0104 hex: Controller to SD Memory Card for instruction operation
0201 hex: Controller to computer
Attached Information 2: Error Details
0001 hex: An SD Memory Card is not inserted.
0002 hex: The SD Memory Card is faulty, the format of the SD Memory Card is not correct, or the SD Memory Card
is not the correct type of card.
0003 hex: The SD Memory Card is write protected.
0204 hex: SD Memory Card backup is prohibited.
0205 hex: Another backup operation is in progress.
0206 hex: Synchronization, online editing, or the Clear All Memory operation is in progress.
0207 hex: A prohibited character is used in the directory name that is specified in the system-defined variable.
0401 hex: The backup was canceled by the user.
0501 hex: The online connection with the Sysmac Studio was disconnected.
Precautions/
Remarks
None

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
