Omron NX1P2 series

6 Troubleshooting
6 - 80
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Attached
information
Attached information 1: Operation type
0101 hex: SD Memory Card to Controller for switch operation on front of CPU Unit
0102 hex: SD Memory Card to Controller for specification with a system-defined variable
0201 hex: Computer to Controller
Attached Information 2: Error Details
0001 hex: An SD Memory Card is not inserted.
0002 hex: The SD Memory Card is faulty, the format of the SD Memory Card is not correct, or the SD Memory Card
is not the correct type of card.
0004 hex: Recovery was executed for the SD Memory Card.
0101 hex: There is no such folder on the SD Memory Card as specified by the _Card1RestoreCmd.DirName sys-
tem-defined variable.
0102 hex: There are no backup files.
0103 hex: The backup files are corrupted.
0104 hex: The contents of the restore command file are not correct or required files are not set to transfer in the
setting of the system-defined variable.
0105 hex: The required transfer data is not in the backup file.
0201 hex: The unit version of the CPU Unit is old.
0202 hex: The model numbers of the CPU Unit are not the same.
0203 hex: The CPU Unit is write-protected.
0205 hex: Another backup operation is in progress.
0206 hex: Synchronization, online editing, or the Clear All Memory operation is in progress.
0211 hex: The database connection service or robot version of the CPU Unit is old.
0212 hex: Restore by system-defined variable is set to Do not use in the Controller Setup.
0213 hex: Password of Restore by system-defined variable in the Controller Setup does not agree with the
_Card1RestoreCmd.Password system-defined variable.
0214 hex: The DIP switch on the CPU Unit is not set to allow starting the restore of SD Memory Card backups by
specification with system-defined variables.
0301 hex: Reading data for restoration failed or the SD Memory Card is faulty.
0501 hex: The online connection with the Sysmac Studio was disconnected.
Precautions/
Remarks
None
