6 Troubleshooting
6 - 82
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Event name SD Memory Card Program Transfer Failed to Start Event code
10320000 hex
Meaning An error was detected in pre-start checks for transferring SD Memory Card programs.
Source PLC Function Module Source details None Detection
timing
When transfer-
ring SD Memory
Card programs is
started
Error attributes Level Observation Recovery --- Log category System
Effects User program --- Operation Not affected.
System-defined
variables
Variable Data type Name
_Card1PrgTransferSta _sPRGTRANSFER_STA SD Memory Card Program Transfer
Status
Cause and
correction
Assumed cause Correction Prevention
Program transfer by system-defined
variable is set to Do not use in the
Controller Setup.
Set Program transfer by system-
defined variable to Use in the Control-
ler Setup.
Set Program transfer by system-
defined variable to Use in the Control-
ler Setup.
Password of Program transfer by sys-
tem-defined variable in the Controller
Setup does not agree with the
_Card1PrgTransferCmd.Password
system-defined variable.
Set Password of Program transfer by
system-defined variable in the Con-
troller Setup to the _Card1PrgTrans-
ferCmd.Password system-defined
variable.
Set Password of Program transfer by
system-defined variable in the Con-
troller Setup to the _Card1PrgTrans-
ferCmd.Password system-defined
variable.
The DIP switch on the CPU Unit is not
set to allow starting the SD Memory
Card program transfer.
Turn OFF all pins on the DIP switch of
the CPU Unit, and then start the SD
Memory Card program transfer.
Turn OFF all pins on the DIP switch of
the CPU Unit, and then start the SD
Memory Card program transfer.
An SD Memory Card is not inserted. Insert an SD Memory Card. Insert an SD Memory Card.
The SD Memory Card type is not cor-
rect.
Replace the SD Memory Card with an
SD or SDHC card.
Use an SD or SDHC card.
The format of the SD Memory Card is
not correct.
Format the SD Memory Card with the
Sysmac Studio, create a folder speci-
fied by the _Card1PrgTransfer-
Cmd.DirName system-defined
variable on the card, and store the
backup files in the folder.
Use a formatted SD Memory Card,
create a folder specified by the
_Card1PrgTransferCmd.DirName
system-defined variable on the card,
and store the backup files in the
folder.
Also, do not remove the SD Memory
Card or turn OFF the power supply
while the SD BUSY indicator is lit.
There is no such folder on the SD
Memory Card as specified by the
_Card1PrgTransferCmd.DirName sys-
tem-defined variable.
Create a folder specified by the
_Card1PrgTransferCmd.DirName
system-defined variable on the SD
Memory Card and store the backup
files in the folder.
There are no backup files in such a
folder on the SD Memory Card as
specified by the _Card1PrgTransfer-
Cmd.DirName system-defined vari-
able.
Either the backup files in the folder
specified by the _Card1PrgTransfer-
Cmd.DirName system-defined vari-
able on the SD Memory Card are
corrupted or required data is not in the
backup files on the SD Memory Card.
Replace the backup files in the folder
specified by the _Card1PrgTransfer-
Cmd.DirName system-defined vari-
able.
If this error occurs again even after
replacing the files, create the backup
files again and place them in the
folder specified by the _Car
d1Prg-
Transfer
Cmd.DirName system-
defined variable.
To Next Page
