A - 7
Appendices
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
A-3 Version Information
A
A-3-1 Relationship between Unit Versions of CPU Units and Sysmac
Studio Versions
Box on the Sysmac Studio. You can use only the functions that are supported by the unit version of
the connected CPU Unit.
Example:
Unit version of CPU Unit: 1.13
Sysmac Studio version: 1.18
Unit version 1.14 of the CPU Unit corresponds to Sysmac Studio version 1.18. However, the unit
version of the connected CPU Unit is unit version 1.13, so select the version 1.13 as the version in
the Select Device Area of the Project Properties Dialog Box.
If you select version 1.13 as the version in the Select Device Area of the Project Properties Dialog
Box, you can use only the functions that are supported by unit version 1.13 of the CPU Unit. You
cannot use functionality that was added for unit version 1.14 or later of the CPU Unit.
Unit Version Settings for Project Devices
• With Sysmac Studio version 1.02 or higher, you can select the unit version in the Select
Device Area of the relevant dialog boxes.
• You can select any unit version that is the same as or earlier than the unit version of the CPU
Unit. For example, if the unit version of the CPU Unit is 1.14, select either 1.13 or 1.14.
• The Sysmac Studio will treat the CPU Unit as a CPU Unit with the unit version that is
selected for the project device. For example, if you set unit version 1.13 for project device,
you can use only the functionality for unit version 1.13 on the Sysmac Studio.
• You can transfer a project to the Sysmac Studio if the unit version that is set for the project
device is the same as or earlier than the unit version of the destination CPU Unit.
• Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504-E1-03 or later) for
details on the Select Device Area of the relevant dialog boxes.
