Omron NX1P2 series User Manual

7
Relevant Manuals
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Learning about error management and
corrections
*1
  
Maintenance

Using motion control 
Using EtherCAT 
Using EtherNet/IP 
*1. Refer to the NJ/NX-series Troubleshooting Manual (Cat. No. W503) for the error management concepts and an overview of the error
items. Refer to the manuals that are indicated with triangles for details on errors for the corresponding Units.
Purpose of use
Manual
Basic information
NX-series CPU Unit Hardware User’s Manual NX-series NX1P2 CPU Unit Hardware User's Manual NJ-series CPU Unit Hardware User’s Manual NJ/NX-series CPU Unit Software User’s Manual NX-series NX1P2 CPU Unit Built-in I/O and Option Board User’s Manual NJ/NX-series Instructions Reference Manual NJ/NX-series CPU Unit Motion Control User’s Manual NJ/NX-series Motion Control Instructions Reference Manual NJ/NX-series CPU Unit Built-in EtherCAT Port User’s Manual NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual NJ-series Database Connection CPU Units User’s Manual NJ-series SECS/GEM CPU Units User’s Manual NJ-series NJ Robotics CPU Unit User’s Manual NJ/NX-series Troubleshooting Manual

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
