Omron OMNUC G5 Series User Manual

3-64
3-4 Cable and Connector Specifications
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
3
Specifications
R88A-CAKF@BR-E
Cable types
400 V:
(For 3,000-r/min
Servomotors of 750W to 2 kW, 2,000-r/min Servomotors of 400 W to 2 kW,
1,000-r/min
Servomotors of 900 W)
Connection configuration and external dimensions
Wiring
Model Length (L)
Outer diameter of
sheath
R88A-CAKF001-5BR-E 1.5 m
12.5 dia.
R88A-CAKF003BR-E 3 m
R88A-CAKF005BR-E 5 m
R88A-CAKF010BR-E 10 m
R88A-CAKF015BR-E 15 m
R88A-CAKF020BR-E 20 m
L
(150)
(φ12.5)
Servo Drive side
Servomotor side
R88D-K@ R88M-K@
Number
A
B
I
D
Brake
Brake
NC
Phase U
Symbol
Servo Drive side
Black-5
Black-6
Black-1
E
F
G
H
C
Phase W
FG
FG
NC
Phase V
Black-3
Green/Yellow
Black-2
Servomotor side
Cable
2.5 mm
2
× 4C + 0.5 mm
2
× 2C
or
AWG14 × 4C + AWG20 × 2C
M4 crimp terminal
[Servomotor side connector]
Right angle plug model
N/MS3108B24-11S (Japan Aviation Electronics)
Cable clamp model
N/MS3057-16A (Japan Aviation Electronics)
0.5
0.5
2.5
2.5
2.5
2.5
