Omron OMNUC G5 Series User Manual

4-29
4-3 Wiring Conforming to EMC Directives
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
4
System Design
External Dimensions
Equalizing Circuits
123
28
4.5
28.5 11
5.5
φ
4.2
41
200
For 3-phase (BXZ series)
For single-phase (BWZ series)
21
28
4.5
28.5 11
5.5
φ
4.2
41
200
(1) (2) (3)
For 3-phase (BXZ series)
For single-phase (BWZ series)
(1) (2)
