4-30
4-3 Wiring Conforming to EMC Directives
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
4
System Design
Noise Filter for Power Supply Input
We recommend using a noise filter for the Servo Drive.
Drive model
Noise filter for power supply input
Model
Rated
current
Phase
Leakage current
(60 Hz) max
Manufac-
turer
R88D-KNA5L-ECT-R
SUP-EK5-ER-6 5 A
Single-
phase
1.0 mA
(at 250 VAC)
Okaya
Electric
Industries
Co., Ltd.
R88D-KN01L-ECT-R
R88D-KN02L-ECT-R
R88D-KN04L-ECT-R
3SUP-HQ10-ER-6 10 A 3-phase
3.5 mA
(at 500 VAC)
R88D-KN01H-ECT-R
SUP-EK5-ER-6 5 A
Single-
phase
1.0 mA
(at 250 VAC)
R88D-KN02H-ECT-R
R88D-KN04H-ECT-R
R88D-KN08H-ECT-R
3SUP-HQ10-ER-6 10 A 3-phase
3.5 mA
(at 500 VAC)
R88D-KN10H-ECT-R
3SUP-HU30-ER-6 30 A 3-phase
3.5 mA
(at 500 VAC)
R88D-KN15H-ECT-R
R88D-KN20H-ECT-R
R88D-KN30H-ECT-R
3SUP-HL50-ER-6B
50 A
3-phase
8.0 mA
(at 500 VAC)
R88D-KN50H-ECT-R
R88D-KN06F-ECT-R
3SUP-HQ10-ER-6 10 A 3-phase
3.5 mA
(at 500 VAC)
R88D-KN10F-ECT-R
R88D-KN15F-ECT-R
R88D-KN20F-ECT-R
3SUP-HL50-ER-6B 50 A 3-phase
8.0 mA
(at 500 VAC)
R88D-KN30F-ECT-R
R88D-KN50F-ECT-R
To Next Page
