12-2 Warnings
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
12
Troubleshooting and Maintenance
Warning List
General Warnings
*1. Set the Warning Output Selection 1 (3440 hex) to the warning type to output to Warning Output 1
(WARN1), and set the Warning Output Selection 2 (3441 hex) to the warning type to output to the
Warning Output 2 (WARN2). If you set these objects to 0, all warning types are output.
*2. Detection of general warnings can be masked with the Warning Mask Setting (3638 hex) and
detection of EtherCAT communications-related warnings can be masked with the Communications
Control (3800 hex). When the bit is set to 1, the warning detection is masked.
*3 The encoder overheating warning is enabled only when using a 20-bit incremental encoder. It is
disabled for all other types of encoders.
Precautions for Correct Use
Do not use any settings for Error Output Selection 1 (3440 hex) and Error Output Selection 2
(3441 hex) other than those given in the above table.
Warning
number
Warning name Warning condition
Warning
Output
Selection
(3440 hex,
3441 hex)
*1
Warning
Mask Setting
(3638 hex)
* 2
A0 hex
Overload
Warning
The load ratio is 85% or more of the
protection level.
1Bit 7
A1 hex
Excessive
Regeneration
Warning
The regeneration load ratio is 85% or
more of the level. 2 Bit 5
A2 hex Battery Warning The battery voltage is 3.2 V or less. 3 Bit 0
A3 hex
Fan Warning The fan stop state continues for 1
second.
4Bit 6
A4 hex
Encoder Com-
munications
Warning
The encoder communications errors
occurred in series more frequently
than the specified value.
5Bit 4
A5 hex
Encoder
Overheating
Warning
*3
The encoder detects the overheat
warning. 6 Bit 3
A6 hex
Vibration
Detection
Warning
Vibrating is detected.
7Bit 9
A7 hex
Life Expectancy
Warning
The life expectancy of the capacitor
or the fan is shorter than the
specified value.
8Bit 2
A8 hex
External
Encoder Error
Warning
The external encoder detects a
warning. 9 Bit 8
A9 hex
External
Encoder Com-
munications
Warning
The external encoder has
communications errors in series
more than the specified value.
10 Bit 10
