Omron OMNUC G5 Series User Manual

A-8
A-1 Object List
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
A
Appendix
Default setting Setting range Unit
Correspond-
ing Pn number
Relevant
control modes
180 / 270
*1
1 to 32767 0.1 Hz Pn101 All
210 / 310
*2
1 to 10000 0.1 ms Pn102 All
0 0 to 5 − Pn103 All
84 / 126
*3
0 to 2500 0.01 ms Pn104 All
380 / 570
*4
0 to 30000 0.1 Hz Pn105 csp
180 / 270
*5
1 to 32767 0.1 Hz Pn106 All
10000 1 to 10000 0.1 ms Pn107 All
0 0 to 5 − Pn108 All
84 / 126
*6
0 to 2500 0.01 ms Pn109 All
300 0 to 1000 0.1% Pn110 csp
50 0 to 6400 0.01 ms Pn111 csp
0 0 to 1000 0.1% Pn112 csp
0 0 to 6400 0.01 ms Pn113 csp
1
0 to 1 − Pn114 All
0 0 to 10 − Pn115 csp
50
0 to 10000 0.1 ms Pn116 csp
50 0 to 20000 − Pn117 csp
33 0 to 20000 − Pn118 csp
33 0 to 10000 0.1 ms Pn119 csp
0 0 to 4 − Pn200 csp
5000 50 to 5000 Hz Pn201 All
2 0 to 20 − Pn202 All
0 0 to 99 − Pn203 All
*1. The default setting is 180 for a Drive for 200 V and 1 kW or greater, or for a Drive for 400 V. It is set to 270 for other Drives.
*2. The default setting is 310 for a Drive for 200 V and 1 kW or greater, or for a Drive for 400 V. It is set to 210 for other Drives.
*3. The default setting is 126 for a Drive for 200 V and 1 kW or greater, or for a Drive for 400 V. It is set to 84 for other Drives.
*4. The default setting is 380 for a Drive for 200 V and 1 kW or greater, or for a Drive for 400 V. It is set to 570 for other Drives.
*5. The default setting is 180 for a Drive for 200 V and 1 kW or greater, or for a Drive for 400 V. It is set to 270 for other Drives.
*6. The default setting is 126 for a Drive for 200 V and 1 kW or greater, or for a Drive for 400 V. It is set to 84 for other Drives.
