2-25
2-4 External and Mounting Dimensions
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2
Models and External Dimensions
Single-phase/3-phase 200 VAC: R88D-KN10H-ECT-R/-KN15H-ECT-R
(900 W to 1.5 kW)
Wall Mounting
External dimensions Mounting dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
86
150
172
4
φ5.2
140 150
70
8.5
86
70
170
40
11
R2.6
R2.6
φ5.2
φ5.2
170 180 150
86
60
40
10
5.2
5.2
40
10
19.5
2.5
172
4
70
φ5.2
2.5
(88)*
(158)*
* Rectangular hole dimensions are reference values.
Rectangular
hole
