4 System Design
4-32
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
• Use a ground plate for the frame ground for each unit, as shown in the above diagrams, and ground
to a single point.
• Use ground lines with a minimum thickness of 3.5 mm
2
, and arrange the wiring so that the ground
lines are as short as possible.
• A no-fuse breaker, surge absorber, and noise filter should be positioned near the input terminal block
(ground plate), and I/O lines should be separated and wired at the shortest distance.
Unit Details
*1 A specified combination of Servo Drive and Linear Motor must be used.
Symbol Name Manufacturer Model Comment
SG Surge absorber Okaya Electric
Industries Co., Ltd.
R·A·V-781BWZ-4
Single-phase 100 VAC
R·A·V-781BXZ-4
3-phase 200 VAC
NF Noise filter Okaya Electric
Industries Co., Ltd.
SUP-EK5-ER-6 Single-phase 100/200 VAC (5 A)
3SUP-HU10-ER-6 3-phase 200 VAC (10 A)
3SUP-HU30-ER-6 3-phase 200 VAC (30 A)
3SUP-HL50-ER-6B 3-phase 200 VAC (50 A)
SD Servo Drive OMRON *1
LM Linear Motor *1
FC1 Clamp core TDK ZCAT3035-1330
FC2 Clamp core
Schaffner
RJ8035
FC3 Clamp core NEC TOKIN
Corporation
ESD-SR-250
TB Switch box
- Controller
