Omron R88D-KN series

4 System Design
4-34
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
 Cable Details
We recommend using a noise filter for the Servo Drive.
Symbol Supplies from Connects to Cable name Length Comment Shielded Ferrite
(1) AC power supply Noise filter Power supply
line
2 m  No No
(2) Noise filter Servo Drive Power supply
line
2 m  No Optional
(3) Servo Drive Linear Motor Power cable 20 m  No Optional
(4) Servo Drive Linear Motor External
encoder cable
20 m  Yes Optional
(5) Switch box Servo Drive I/O cable 2 m  No Optional
(6) Frame ground Noise filter FG line 1.5 m  No No
(7) Frame ground Noise filter FG line 1.5 m  No No
(8) AC power supply Controller Power supply
line
1.5 m  No No
Noise Filter for Power Supply Input
Servo Drive model
Noise filter for power supply input
Model
Rated
current
Phase
Leakage current
(60 Hz) max
Manufacturer
R88D-KN01L-ECT-L
SUP-EK5-ER-6 5 A
Single-
phase
1.0mA
(at 250VAC)
Okaya
Electric
Industries
Co., Ltd.
R88D-KN02L-ECT-L
R88D-KN04L-ECT-L 3SUP-HQ10-ER-6 10 A 3-phase
3.5mA
(at 500VAC)
R88D-KN01H-ECT-L
SUP-EK5-ER-6 5 A
Single-
phase
1.0mA
(at 250VAC)
R88D-KN02H-ECT-L
R88D-KN04H-ECT-L
R88D-KN08H-ECT-L 3SUP-HQ10-ER-6 10 A 3-phase
3.5mA
(at 500VAC)
R88D-KN10H-ECT-L
3SUP-HU30-ER-6 30 A 3-phase
3.5mA
(at 500VAC)
R88D-KN15H-ECT-L
R88D-KN20H-ECT-L
R88D-KN30H-ECT-L
3SUP-HL50-ER-6B 50 A 3-phase
8.0mA
(at 500VAC)
R88D-KN50H-ECT-L
R88D-KN06F-ECT-L
3SUP-HQ10-ER-6 10 A 3-phase
3.5mA
(at 500VAC)
R88D-KN10F-ECT-L
R88D-KN15F-ECT-L
R88D-KN20F-ECT-L
3SUP-HU30-ER-6 30 A 3-phase
3.5mA
(at 500VAC)
R88D-KN30F-ECT-L
R88D-KN50F-ECT-L
R88D-KN01L-ECT-L
SUP-EK5-ER-6 5 A
Single-
phase
1.0mA
(at 250VAC)
R88D-KN02L-ECT-L
R88D-KN04L-ECT-L 3SUP-HU10-ER-6 10 A 3-phase
3.5mA
(at 500VAC)
R88D-KN01H-ECT-L
SUP-EK5-ER-6 5 A
Single-
phase
1.0mA
(at 250VAC)
R88D-KN02H-ECT-L
R88D-KN04H-ECT-L
R88D-KN08H-ECT-L 3SUP-HU10-ER-6 10 A 3-phase
3.5mA
(at 500VAC)
R88D-KN10H-ECT-L
3SUP-HU30-ER-6 30 A 3-phase
3.5mA
(at 500VAC)
R88D-KN15H-ECT-L
