Omron R88D-KN series User Manual

4-57
4 System Design
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
4-4 Regenerative Energy Absorption
4
4-4-4 Connecting an External Regeneration Resistor
*1 Select a combination that has an absorption capacity greater than the average regeneration power (Pr).
*2 Do not use a combination with resistance values lower than the allowable minimum regeneration resistance of
each drive. For information on the allowable minimum regeneration resistance, refer to 4-4-2 Servo Drive Regenera-
tion Absorption Capacity on page 4-53.
Precautions for Safe Use
Surface temperatures on regeneration resistance can reach 200C.
Do not place objects that tend to catch fire nearby. To prevent people from touching them, install
a cover that enables heat dissipation.
Regeneration
absorption
capacity
*1
140 W 280 W 560 W
Model R88A-RR22047S
R88A-RR22047S1
R88A-RR22047S
R88A-RR22047S1
R88A-RR22047S
R88A-RR22047S1
Resistance
value
*2
23.5  47  23.5 
Connection
method
Regeneration
absorption
capacity
*1
180 W 360 W 1440 W
Model R88A-RR50020S R88A-RR50020S R88A-RR50020S
Resistance
value
*2
20  10  10 
Connection
method
R
R
R
R
R R
R R
R R
R R
R R
R R
R R
R R
R R
R R
R
R
R
R
R
R R
R R
R R
R R
R R
R R
R R
R R
