G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
Event name External Encoder Connection Error Event code 080C0000 hex
Meaning A disconnection was detected because communications between the external encoder and the Servo Drive were
stopped more frequently than the specified value.
Source EtherCAT Master Function Module Source details Slave Detection
timing
Continuously
Error attributes Level Minor fault Recovery Error reset (after
cycling slave
power)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
The wiring is incorrect. Wire the external encoder correctly as
shown in the wiring diagram. Correct
the connector pin connections.
Wire the external encoder correctly as
shown in the wiring diagram. Connect
the connector pins correctly.
Attached
information
None
Precautions/
Remarks
“50” is displayed on the Servo Drive front panel and F050 is given as the AlarmCode (4001 hex).
Event name External Encoder Communications Data Error Event code 080D0000 hex
Meaning There was a communications error in data from the external encoder.
Source EtherCAT Master Function Module Source details Slave Detection
timing
Continuously
Error attributes Level Minor fault Recovery Error reset (after
cycling slave
power)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
There is insufficient external encoder
power supply voltage.
Provide the required external encoder
power supply voltage 5 VDC 5%
(4.75 to 5.25 V).
Provide the required external encoder
power supply voltage 5 VDC 5%
(4.75 to 5.25 V).
Noise If the motor cable and the external
encoder cable are bundled together,
separate them. Connect the shield to
FG.
If the motor cable and the external
encoder cable are bundled together,
separate them. Connect the shield to
FG.
Attached
information
None
Precautions/
Remarks
“50” is displayed on the Servo Drive front panel and F150 is given as the AlarmCode (4001 hex).
