Appendicies
A-122
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
Event name Object Corrupted Event code 14AD0000 hex
Meaning The checksum data in non-volatile memory is corrupted.
Source EtherCAT Master Function Module Source details Slave Detection
timing
When
establishing
communications
after turning ON
power to the
slave
Error attributes Level Minor fault Recovery Error reset (after
cycling slave
power)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
Non-volatile memory failure Replace the Servo Drive. None
Attached
information
None
Precautions/
Remarks
“37” is displayed on the Servo Drive front panel and F237 is given as the AlarmCode (4001 hex).
Event name Motor Setting Error Event code 28010000 hex
Meaning Settings associated with the motor and external encoder are missing.
Source EtherCAT Master Function Module Source details Slave Detection
timing
Continuously
Error attributes Level Minor fault Recovery Error reset (after
cycling slave
power)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
Settings associated with the motor
and external encoder are missing.
Check the specifications of the motor
and external encoder and provide the
required settings.
Check the specifications of the motor
and external encoder and provide the
required settings.
Attached
information
None
Precautions/
Remarks
“50” is displayed on the Servo Drive front panel and F060 is given as the AlarmCode (4001 hex).
