G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
Event name Overspeed 2 Event code 38400000 hex
Meaning The motor speed exceeded the value set on Overspeed Detection Level Setting at Immediate Stop (3615 hex).
Source EtherCAT Master Function Module Source details Slave Detection
timing
While power is
supplied to motor
Error attributes Level Minor fault Recovery Error reset (after
resetting slave
errors)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
The velocity command value is too
large.
Reduce the velocity. Adjust the input
frequency, dividing ratio, and
multiplication ratio of the command
pulse.
Set the velocity command value in a
range that does not exceed the
overspeed detection level at
immediate stop. Check the input
frequency, dividing ratio, and
multiplication ratio of the command
pulse.
There is overshooting. Adjust the gain. Do not make the gain too large.
The wiring is incorrect. Wire the encoder correctly as shown
in the wiring diagram.
Wire the encoder correctly as shown
in the wiring diagram.
Attached
information
None
Precautions/
Remarks
“26” is displayed on the Servo Drive front panel and F126 is given as the AlarmCode (4001 hex)
Event name Command Error Event code 38410000 hex
Meaning The position command variation after the electronic gear exceeded the specified value.
Source EtherCAT Master Function Module Source details Slave Detection
timing
Continuously
Error attributes Level Minor fault Recovery Error reset (after
cycling slave
power)
Log category System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Remedy Prevention
The change in position command is
too large.
Reduce the electronic gear ratio. Adjust the electronic gear ratio so that
the changes in the position command
are not too large.
The backlash compensation amount
is too large.
Reduce the backlash compensation
amount.
Adjust the backlash compensation
amount so that the changes in the
position command are not too large.
Attached
information
None
Precautions/
Remarks
“27” is displayed on the Servo Drive front panel and F427 is given as the AlarmCode (4001 hex)
