Omron R88D-KN series User Manual

2-11
2 Models and External Dimensions
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
2-4 External and Mounting Dimensions
2
2-4-1 Servo Drive Dimensions
 Wall Mounting
External dimensions Mounting dimensions
 Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
Single-phase 100 VAC: R88D-KN04L-ECT-L (400 W)
Single-phase/3-phase 200 VAC: R88D-KN08H-ECT-L (750 W)
172
4
65
150
150 140
50
7.5
65
70
2-M4
65
40
20
φ5.2
R2.6
20
40
5.2
180 170 150
172
4
19.5
2.5
170
20
70
2-M4
(67)*
(158)*
* Rectangular hole dimensions are reference values.
Rectangular
hole
