Omron R88D-KN series User Manual

2 Models and External Dimensions
2-18
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
 Wall Mounting
External dimensions Mounting dimensions
 Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
3-phase 400 VAC: R88D-KN06F-ECT-L/-KN10F-ECT-L/
-KN15F-ECT-L (600 W to 1.5 kW)
92
150
172
4
150 140
70
14.5
70
2-M4
92
92
60
40
10
φ5.2 φ5.2
170 180 150
5.2 5.2
10
40
R2.6
172
70
4
19.5
2.5
40
18
6
(94)*
170
(158)*
4-M4
* Rectangular hole dimensions are reference values.
Rectangular
hole
